Description
Model:109-643
Series:San Ace 160
Manufacturer:Sanyo Denki
Dimensions: 160x160x51mm
Voltage: 230AC
Frequency: 50/60 Hz
Current Draw: Around 0.16A to 0.21A
Locked rotor current: 0.32/0.31A
Power: 37.5/33W
Air volume: 254.4/300.4CFM
Air pressure: 156.8/166.6Pa
Noise: 56/60dB
Service life: 25000/60°C
Speed: Typically 2850 RPM at 50Hz and 3350 RPM at 60Hz
Noise Level: Around 56 dBA at 50Hz and 60 dBA at 60Hz
Bearing Type: Ball Bearing
Frame Material: Aluminum
Impeller Material: Plastic
Features: Typically includes locked rotor protection and a speed sensor
Termination: Wire Leads
Operating Temperature: -10°C to +60°C
Expected Life: Has a long operational life
Weight (Mass): Approximately 1100 g (1.1 kg)
Certifications: May include CE, CSA, PSE, TUV, UR certifications
Type: AC Axial Fan
