Description
Model:3615KL-04W-B7612
Brand:NMB-MAT
Dimensions:92×92×38mm
Voltage: DC12
Current: 1.60A
Power: 19.2W (12V×1.6A)
Airflow:35CFM (~99m³/h)
Speed:2800 RPM
Noise:Low-noise design (specific dB not stated)
Rotation Direction: Counterclockwise (viewed from fan blade side)
Bearing Type: High-precision NMB dual-ball bearing (maintenance-free)
Frame Material: PBT + 30% fiberglass + VO-grade flame retardant (injection-molded)
Blade Material: PBT + 30% fiberglass + VO-grade flame retardant (7 blades)
Operating Temperature: -20°C to +70°C
Storage Temperature: -40°C to +70°C
Insulation Resistance: >500MΩ1
Withstand Voltage: 500V/1min (leakage current ≤0.5mA)
Lifespan: ≥80,000 hours at 25°C
Interface: 4-wire PWM thermal control (customizable to 2-wire/3-wire)
Applications：
Server CPU cooling (e.g., HP ML570 G2)
Cabinet ventilation, air conditioning, automotive industries
New original NMB 3615KL-04W-B76 9238 12V HP ML570 G2 server CPU fan
