Description
The ebmpapst 4318/17 IU is a high-performance DC Axial Fan measuring 119x119x32mm. It operates on 48VDC with a rated current of 0.113A and a power consumption of 5.4W, delivering a powerful airflow of 100.1 CFM and a static pressure of 70.0 Pa. The fan features a durable ball bearing system for long-term reliability and quiet operation, making it an ideal cooling solution for various industrial and electronic applications.
4318/17 IU Fan Parameters
Model: 4318/17 IU
Manufacturer: ebmpapst
Type: DC Axial Fan
dimensions: 119 x 119 x 32 mm
Rated Voltage: 48 V DC
Operating Voltage Range: 40 to 53 V DC
Rated Current: 0.113 A
Rated Input Power: 5.4 W
Rated Speed: 2800 RPM
Airflow: 100.1 CFM (2.80 m³/min)
Static Pressure: 70.0 Pa (0.281 in H₂O)
Noise: 45.0 dB(A)
Bearing Type: Ball Bearing
Operating Temperature: -20 to 66 °C
Frame Material: Polybutylene Terephthalate (PBT), Fiberglass Reinforced
Blade Material: Polyamide (PA), Nylon, Fiberglass Reinforced
Termination Style: 3-wire leads
Approvals: CCC, CE, CSA, EAC, UL, VDE
Application
The 4318/17 IU is commonly used in applications requiring robust and efficient cooling, such as power supplies, control cabinets, and industrial equipment, where its high airflow and reliability are essential for maintaining optimal operating temperatures.
