Description
The ebmpapst W2D250-EA26-11 is an efficient AC Axial Fan measuring 250 mm in diameter. Operating on 230V AC with frequencies of 50/60 Hz, this fan is designed for applications requiring a high airflow of up to 1500 m³/h and a static pressure up to 245 Pa. It features a durable ball bearing system and a terminal box for easy connection, making it a robust and reliable solution for industrial cooling needs.
W2D250-EA26-11 Fan Parameters
Model: W2D250-EA26-11
Manufacturer: ebmpapst
Type: AC Axial Fan
Dimensions: 250 mm diameter
Rated Voltage: 230V AC
Frequency: 50/60 Hz
Rated Speed: 2750 RPM (50 Hz), 3100 RPM (60 Hz)
Rated Input Power: 180W (50 Hz), 245W (60 Hz)
Airflow: 1350 m³/h (50 Hz), 1500 m³/h (60 Hz)
Static Pressure: 215 Pa (50 Hz), 245 Pa (60 Hz)
Noise Level: 7.2 B (50 Hz), 7.8 B (60 Hz)
Bearing Type: Ball Bearing
Termination: Terminal box
Application
The W2D250-EA26-11 is well-suited for a variety of cooling and ventilation tasks. It is frequently employed in systems for ventilation, air conditioning, and refrigeration, where dependable and efficient air circulation is crucial for maintaining optimal operating conditions. Its design allows for high airflow at medium pressure, making it ideal for moving air through heat exchangers, condensers, and evaporators in industrial settings.
