Description
The NMB 3108NL-04W-B50 is a high-performance DC axial fan from NMB measuring 80 x 80 x 20 mm. It operates on 12 VDC, with a rated current of 0.36 A. This fan delivers a strong airflow of 44 CFM and a rated speed of 3750 RPM. It features a durable ball bearing system and is terminated with 3 wire leads, making it a reliable cooling solution for various electronic applications.
3108NL-04W-B50 Fan Parameters
Model: 3108NL-04W-B50
Manufacturer: NMB Technologies Corporation
Type: DC Axial Fan
Dimensions: 80 x 80 x 20 mm
Mass: 85 g
Rated Voltage: 12 VDC
Operating Voltage Range: 6 to 13.8 VDC
Rated Current: 0.36 A
Rated Input Power: 4.32 W
Rated Speed: 3750 RPM
Airflow: 44 CFM (1.25 m³/min)
Static Pressure: 0.2 in H₂O (50.1 Pa)
Noise Level: 42 dB(A)
Bearing Type: Ball Bearing
Life Expectancy: 40,000 h at 60°C
Termination: 3 wire leads
Application
The 3108NL-04W-B50 is well-suited for cooling a variety of electronic equipment, including servers, power supplies, and control cabinets. Its compact size and high-performance specifications make it ideal for applications where efficient and reliable air circulation is essential for maintaining optimal operating temperatures.
