AFB0924SH-A 24V 0.5A inverter axial fan

Description

Model: AFB0924SH-A
Manufacturer: Delta Electronics
Type: DC Axial Fan
Dimensions: 92x92x25mm
Nominal Voltage: 24VDC
Operating Voltage Range: 14V to 26.4V DC
Current: 0.50A
Power Consumption: 12W
Speed: 4800RPM
Airflow: 102.6CFM
Static Pressure: 0.526 In H2O (approx. 131 Pa)
Noise Level: 53dBA
Bearing Type: Dual Ball Bearing
Life Expectancy: 70,000 Hours (at 40°C, L10)
Termination: 2-wire leads
Frame Material: Plastic
Impeller Material: Plastic
Features: Brushless DC motor, polarity protected, locked rotor protection.
Delta Brand new original authentic AFB0924SH 24V 0.5A 9225 inverter fan
The Delta AFB0924SH-A is a high-performance 24V DC axial fan, measuring 92mm x 92mm x 25mm, manufactured by Delta Electronics. This fan is engineered for demanding cooling applications that require substantial airflow and static pressure. It features durable dual ball bearings, contributing to a long operational lifespan of 70,000 hours at 40°C.Drawing 0.50A of current, it consumes 12.0W of power. This fan operates at a high speed of 4800 RPM, delivering a strong 102.6 CFM of airflow and generating 0.526 inches of H2O static pressure, with a notable 53 dBA noise level. Equipped with 2-wire leads and featuring locked rotor protection, the Delta AFB0924SH-A is an excellent choice for cooling components in servers, power supplies, industrial control systems, and high-performance computing devices that require robust and reliable thermal management.
