Voltage: DC 48V
Plug: 4 wire plug PWM
Bearing: double ball bearing
Air volume: 334.79CFM
Wind pressure: 47.86mmH2O
Bearing method: double ball
4-wire with speed measurement for vehicles, refrigerators and other equipment.
The nominal current is 0.76A, and the actual running test current is about 0.5A, and the air volume is large.
The fan voltage can be operated at 20V. The test is as follows:
Voltage 20V = current 0.2A.
Voltage 24V = current 0.26A.
Voltage 36V = current 0.38A.
Of course, when the voltage is low, the air volume is small and the wind is very light.
Dimensions 180mm x 175mm x 75mm and weighs approximately 800 grams.
