EFB0924SHF Delta DC24V 0.38A axial cooling fan

$9.99

SKU: EFB0924SHF Category: Brand:

Description

Delta New original authentic EFB0924SHF 24V 0.38A 9032 cooling fan
Model Number: EFB0924SHF
Manufacturer: Delta Electronics
Series: EFB
Fan Type: DC Brushless Axial Fan
Dimensions: 90x90x32mm
Rated Voltage: 24VDC
Operating Voltage Range: 7 VDC to 27.6 VDC
Rated Current: 0.38A
Input Power: 9.12W
Wiring: 2 Wire Leads
Bearing Type: Double Ball Bearing
Rotational Speed RPM: 3500 RPM to 4800 RPM
Maximum Airflow: 35 CFM to 135.8 CFM
Maximum Static Pressure: 0.422 in H2O to 0.650 in H2O
Noise Level: 35 dBA to 52 dBA
Frame Material: Plastic
Impeller Blade Material: Plastic
Protection Functions: Locked Rotor Protection
Operating Temperature Range: -10°C to +70°C
Expected Life: 70,000 Hours at 40°C
Mass: 140g to 205.83g
Safety Approvals: CE, UL, CSA, VDE

The Delta EFB0924SHF is a powerful 90x90x32mm DC axial fan from Delta’s EFB series. Operating on 24VDC, it uses 9.12W of power with a current draw of 0.38A. This fan features robust double ball bearings for extended reliability and a long operational life of 70,000 hours at 40°C.

It’s engineered to deliver significant airflow and static pressure, making it highly effective for cooling components in confined or restrictive spaces. While the exact performance can vary slightly, you can expect a wide airflow range from 35 CFM to 135.8 CFM and noise levels between 35 dBA and 52 dBA, reflecting its powerful output. This fan is an excellent choice for cooling inverters, server power supplies, industrial control cabinets, and other electronic systems where strong and dependable thermal management is crucial.
