Description
The Sanyo Denki 9GV1512P5M031 is a high-performance 12VDC axial fan from the San Ace 150 series, with dimensions of 150x150x50mm. Utilizing advanced Guide Vane technology, the fan provides excellent performance with 224CFM (380.6m³/h) of airflow and 0.530inchH₂O (132Pa) of static pressure while operating at 3000RPM. It consumes 14.4W of power and is built with durable plastic materials and ball bearings for a long service life. The 4-wire termination provides integrated PWM control for precise speed regulation and a speed sensor (Tachometer/FG) for monitoring. It also features locked rotor and reverse polarity protection. It is commonly used for cooling high-density servers, telecommunications equipment, power supply units, and industrial machinery.
9GV1512P5M031 Fan Parameters
Manufacturer: Sanyo Denki
Model: 9GV1512P5M031
Fan Type: DC Axial Fan
Dimensions: 150 x 150 x 50 mm
Rated Voltage: 12 VDC
Operating Voltage Range: 10.2 ~ 13.8 VDC
Current Rating: 1.20 A
Power Consumption: 14.4 W
Airflow: 224 CFM (380.6 m³/h)
Static Pressure: 0.530 inch H₂O (132 Pa)
Speed: 3000 RPM
Noise Level: 53.0 dB(A)
Bearing Type: Ball Bearing
Termination: 4 Wire Leads
Features: PWM Control, Speed Sensor (Tachometer/FG), Locked Rotor Protection, Reverse Polarity Protection
Housing Material: Plastic
Impeller Material: Plastic
Operating Temperature: -20 °C ~ 70 °C
Lifetime @ Temp: 70,000 Hours @ 40 °C, 40,000 Hours @ 60 °C
Weight: 450 g
Application: This Sanyo Denki DC axial fan is suitable for cooling high-density servers, telecommunications equipment, and industrial machinery.
