Description
The ADDA AD1248MB-F51 is a high-performance DC Axial Fan with dimensions of 120 x 120 x 38 mm. It operates on a high nominal voltage of 48 V DC and features a reliable Ball Bearing system with 2 Wire Leads termination. Both the frame and the impeller are constructed from durable Plastic material. This fan is highly efficient, drawing a nominal current of 0.14 A for a power consumption of 6.72 W. It delivers an air flow of 159.71 m3/h at a speed of 2540 RPM and a static pressure of 60.77 Pa, while maintaining a low noise level of 41.0 dBA. This unit is an ideal choice for cooling applications in telecommunications equipment, server racks, and industrial power systems that require a 48 V power source.
AD1248MB-F51 Fan Parameters
Model: AD1248MB-F51
Manufacturer: ADDA
Type: DC Axial Fan
Nominal Voltage: 48 V DC
Current Draw: 0.14 A
Power Consumption: 6.72 W
Airflow: 159.71 m3/h
Static Pressure: 60.77 Pa
Speed: 2540 RPM
Noise Level: 41.0 dBA
Dimensions: 120 x 120 x 38 mm
Weight: 297 g
Bearing Type: Ball Bearing
Frame Material: Plastic
Impeller Material: Plastic
Termination: 2 Wire Leads
Application
The AD1248MB-F51 is suitable for basic cooling in 48 V DC systems, making it an excellent component for telecom switches, routers, or medium-sized servers where a balance of stable airflow, moderate static pressure, and low operational noise is required.
