KAKU KA1725HA2BAT AC220V cooling fan

(1 customer review)


994 in stock

SKU: KA1725HA2BAT Category: Brand:


Specifications: 172x150x51mm
Brand: KAKU
Model number: KA1725HA2BAT
Bearing structure: B: BALL (ball bearing)
Voltage: AC 220 ~ 240V
Power: 38/35 (W)
Frequency: 50/60 (Hz)

  Speed: 2700-3100 (R / min)

  Air volume: 5.37 / 6.88 (M3 / min)

  Noise: 56/61 (dB-A)

  Weight: 950 (g)

  Packing: without screws, in a separate box, in ordinary cardboard boxes, 24 units per 1 carton;

  Frame: Black-painted aluminum alloy die-casting anti-corrosion and moisture-proof structure;

  Wind blade: one-shot injection molding, PBT + 30% glass line + VO flame retardant;

  Bearing: low-noise imported ball bearing;

  Insulation: The enameled wire adopts Class B insulation and has a temperature resistance of 120 degrees Celsius;

  Wiring method: lead

  Insulation resistance: above 500 megohms;

  Withstand voltage: leakage current 0.5mA. Withstand voltage 1500V / 1 minute;

  Operating voltage: 220V (voltage range: 185V ~ 245V)

  Fan rotation direction: clockwise when viewed from the direction of the fan blades; wind from the direction of the trademark.

  Ambient temperature for use (℃): -20 ℃ ~ 75 ℃ B: (ball bearing)

  Life: working environment temperature 40 ℃ B: (ball bearing) 60000 (hour)

  Long life, can work continuously for 24 hours.

Additional information

Weight 1 kg
Model Number


Brand Name







Single Fans

Radiator Type


1 review for KAKU KA1725HA2BAT AC220V cooling fan

  1. 99go

    I ordered 200 pieces more than 10 times, but I am receiving consistent products without a single error.
